BTClock — Quickstart

A 10-minute walkthrough that takes a powered-up BTClock and gets it joined to your Wi-Fi, set to your timezone, and rotating through Bitcoin screens.

If you want the deep dive into every setting, read HANDBOOK.md once the device is on the network.

This guide targets the two production variants — Rev A (4 MB, 2.13" panels) and Rev B (8 MB, 2.13" panels, with frontlight + ambient sensor). The 8-panel V8 board and the 2.9" Rev A build are out of scope here; treat them as prototypes.

What you'll need

  • The BTClock itself.
  • A USB-C cable and a 5 V power source. The BTClock draws < 250 mA in steady state — any modern phone charger works.
  • A 2.4 GHz Wi-Fi network. The ESP32-S3 radio has no 5 GHz support.
  • A phone or laptop on the same network for the WebUI.

1. Power up

Plug the USB-C cable in. On first boot you'll see the LEDs run a short rainbow self-test, then the panels paint a provisioning screen showing:

Provisioning first-boot screen

  • The hotspot name, e.g. BTClock-XXXX (the last two bytes of the device MAC, in hex)
  • A randomly-generated 8-character WPA2 password (mixed case, no visually-ambiguous characters like 0 / O / 1 / l)
  • A QR code that encodes WIFI:T:WPA;S:<ssid>;P:<password>;;

The password is generated once, persisted to NVS, and reused across reboots — note it down or scan the QR.

2. Join the BTClock's hotspot

Scan the QR with your phone (it'll join automatically) or connect manually:

  • SSID: BTClock-XXXX
  • Security: WPA2
  • Password: the 8 characters shown on the panel

Most phones detect the captive portal and pop the join sheet automatically. If yours doesn't, open http://192.168.4.1 in a browser.

3. Pick your home Wi-Fi

The captive portal lists nearby SSIDs. Select yours, type the password, hit save. The device persists the credentials, reboots, and rejoins as a normal STA client. The provisioning hotspot disappears on the next boot.

If you typed the password wrong, wait wpTimeout seconds (15 minutes by default) — the device reboots back into provisioning mode so you can retry.

4. Find the BTClock on your network

Once the device is on Wi-Fi, the panels show the rotation screens. To open the WebUI:

  • mDNS — most desktops and Linux machines support it: visit http://btclock-xxxxxx.local (where xxxxxx is the lowercase full-MAC suffix, also visible in the WebUI's System info card).
  • By IP — your router will list the device as btclock-xxxxxx in its DHCP table; visit that IP directly. The IP is also the Status → System info → IP line once you're connected.

5. Open the WebUI

You'll see three columns:

  1. Control (left) — push text to the panels, set LED colour, drive the frontlight (Rev B), trigger a firmware update or factory reset.
  2. Status (centre) — live preview of what the panels show right now, screen-cycle timer, DND state, signal strength, uptime.
  3. Settings (right) — the long form of everything below.

6. Set timezone and currencies

In Settings → Timezone: pick your IANA zone (e.g. Europe/Amsterdam). The BTClock and time-based DND windows will track DST automatically. Saved live, no reboot.

In Settings → Data sources → Currencies: drag-reorder your ticker / sats-per-currency rotation. Defaults are USD, EUR, JPY.

7. Pick the screens you want

In Settings → Screens: toggle each rotation screen on or off, and drag to set the order. The default catalogue is:

  • Block height
  • Time
  • Halving countdown
  • Block fee rate
  • Sats per dollar (Moscow time)
  • BTC ticker
  • Market cap
  • Bitcoin supply
  • Mining pool hashrate / earnings
  • Bitaxe hashrate / best difficulty

Auto-rotate cadence is in Settings → Screen specific → Time per screen (default 30 minutes — yes, e-paper is slow on purpose; lower it to 1 minute if you'd rather see motion). The Handbook → Screen catalogue shows what each screen looks like.

8. (Optional) First-day tweaks

  • LED colour (Control card → LEDs) — the default is the BTClock orange #E04300. The rear LED strip flashes this colour on every new block.
  • Frontlight (Rev B only — Control card → Frontlight) — pick always-on, ambient-driven, or off.
  • Mining pool (Settings → Mining pool) — drop in your pool's user / payout-address / API key. Defaults to noderunners global stats so the screen renders without per-user credentials. See the pool field guide for what to fill in per pool.
  • Bitaxe (Settings → Bitaxe) — point at your miner's hostname or IP and the Bitaxe screens light up.
  • Do Not Disturb (Settings → Do Not Disturb) — schedule a window where the LEDs stay dark; useful in a bedroom. The e-paper itself doesn't emit light, so panel content stays visible.

What's next

  • The full reference — every screen, every setting, every API endpoint — is in HANDBOOK.md.
  • A Home Assistant custom integration is at https://github.com/dsbaars/homeassistant-btclock — entities for every data screen plus services for screen-push and LED control.
  • A web-based ESP-S3 flasher (no toolchain, just Chrome) lives at https://web-flasher.btclock.dev/ — the easiest way to flash a fresh board or recover from a bad firmware.
  • Want to build firmware yourself? See BUILD_FROM_SOURCE.md.
